Merida Big Nine 20-3X Bike

Product Description

Aluminium hardtail, sporting fast-rolling 29er wheels, 100 mm of front suspension and a triple chainset setup, giving you plenty of gears to choose from and lots of comfort and control out on the trails.

Triple chainring equipped entry-level 29er aluminium hardtail featuring a more upright and, therefore, more comfortable riding position than our more race-focused hardtails. The riding position puts less strain on the lower back and also improves the visibility of what lies ahead. A 100 mm suspension fork from SR Suntour and hydraulic disc brakes improve comfort and control even further.

Mountain biking is one of the most varied cycling disciplines and probably the most demanding when it comes to equipment. While full suspension bikes offer amazing riding characteristics, the classic hardtail remains one of the purest tools for the job. Our 29er wheel equipped BIG.NINE range comes in carbon and aluminium and features multiple geometry options. The carbon and LITE framed BIG.NINE, with its racing geometry, is an ideal companion on XC and marathon race tracks whilst the more relaxed geometry of the BIG.NINE TFS and SPEED offers a more comfortable, upright riding position. Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we could gain in almost half a century of bike production and manufacturing. The BIG.NINE range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.

• Double butted aluminium frame with 29er wheels
• Less aggressive and more upright geometry for maximum control and comfort
• SR Suntour 100 mm travel suspension fork with lockout
• Shimano 8-speed drivetrain with triple chainring setup
• Hydraulic disc brakes
• Internal cable routing

SPECIFICATIONS

FRAME BIG.NINE TFS III

• material: aluminum
• 29x2.25" max. wheelsize
• 135x9mm axle standard
• BSA bottom bracket standard

FRAME SIZE S, M, L, XL, XXL FORK SR Suntour XCT30 HLO

• Coil
• 100mm suspension travel
• lockout
• 29x2.25" max. wheelsize

BRAKES Power DS100

• 2 piston
• hydraulic disc brake

ROTORS Shimano RT10

• 160 mm

HEADSET MERIDA M2345 HANDLEBAR MERIDA CC

• material: aluminium
• 690mm width
• 15mm rise

HANDLEBAR STEM MERIDA CC

• material: aluminium
• 31.8mm diameter
• 6° stem angle
• 70 mm-S, 80 mm-M, 90 mm-L, 100 mm-XL, 110 mm-XXL

GRIP MERIDA EC DERAILLEUR (F) Shimano FD-TY700 DERAILLEUR (R) Shimano RD-M360 SHIFTERS Micro Shift TS39-L / Micro Shift TS39-8R SEAT POST MERIDA CC

• material: aluminium
• 30.9mm diameter
• 15mm setback

SEAT CLAMP MERIDA COMP QR SADDLE MERIDA SPORT COMFORT PEDAL VP VPE-891 CHAIN SUNRACE M84 CRANK Shimano TY301

• 42-34-24 teeth
• 170 mm-S, 175 mm-M/XXL

FREEWHEEL SUNRACE CSM668

• 11-32 teeth
• 8 speed

BOTTOM BRAKET FSA TH-7420ST-W, CARTRIDGE BEARING HUBS Shimano TX505

• 100x9mm width front hub
• 32 spoke holes
• Centerlock
• 135x9mm width rear hub
• 32 spoke holes
• Centerlock

RIM MERIDA CC

• 17mm inner width
• material: aluminium

TYRE FRONT MERIDA K1080

• 29x2.2"
• wire

TYRE REAR MERIDA K1080

• 29x2.2"
• wire

SPOKES Black steel MAX. WEIGHT 135 kg

HIGHLIGHTS

MULTIPLE FRAME OPTIONS

Besides offering the BIG.NINE in a full carbon version, we also have BIG.NINE LITE and BIG.NINE/ SEVEN TFS aluminium frames in our range. While the LITE features the same race-proven geometry as the carbon models, the TFS bikes offer a more relaxed geometry, through a shorter top tube and a higher head tube, resulting in a more upright riding position and enhanced trail visibility. The TFS frames feature internal cable routing (except the BIG.NINE/BIG.SEVEN 15), smooth welding, tapered head tube, inboard disc mounts, and mounts for fenders, rear rack and kickstand.

THIS IS WHAT WE DO

Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we were able to gain in 48 years of bike production and manufacturing. The BIG.NINE and BIG.SEVEN range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.

TECHNOLOGIES

RACELITE 61 ALUMINIUM

We use a minimum of 6061 aluminium. The pay back is that it’s possible to make lighter and more advanced frames. We use an additional heat treatment and double-butted wall thicknesses to produce light and stiff frames.

TFS - TECHNO FORMING SYSTEM

Technoforming is a mechanical forming process, shaping the tubes by using negative moulds, at times combined with an internal metal core.

F-MOUNT

‘F-Mount’ equipped bikes have integrated fittings for mud guards (some bikes require model specific mud guards), making fitting fast and simple.

K-MOUNT

Integrated mount on the chainstay to fit a MERIDA kickstand (or any commercial kickstand).

C-MOUNT

‘C-Mount’ equipped bikes have the fixing points for a rear rack already integrated (some bikes require model specific rear rack), making fitting fast, simple and reliable.
